List of offshore wind farms in Denmark

This is a complete list of operational, offshore wind farms in Denmark (within the national maritime boundaries).

This information is gathered from multiple Internet sources,[1][2] and primarily the 4C Offshore's Global Offshore Wind Farm Map and Database and is current up to 2014. Tariff data is supplied by the Danish Energy Agency.[3] The name of the Wind Farm is the name used by the Energy Company when referring to the Farm and is usually related to a shoal or the name of the nearest town on shore. The Wind Farm part is implied and hence removed for clarity.

List

The list is sorted by capacity, but it can be sorted in any way by clicking once or twice on the triangle symbols ( Δ ) at the top in each column.

Wind farm Cap.
(MW)
Turbines Where When Build
Cost
Cap.
fac.
Depth
range (m)
km to
shore
Country Owner Refs.
Anholt 400 111 × Siemens SWP 3.6-120 56°36′00″N 11°12′36″E / 56.60000°N 11.21000°E / 56.60000; 11.21000 (Anholt 400MW) 2013 DKK10b 46.7% 15-19 23  Denmark DONG, others [w 1][4][5][6][7]
Horns Rev II 209 91 × Siemens SWP 2.3-93 55°36′00″N 7°35′24″E / 55.60000°N 7.59000°E / 55.60000; 7.59000 (Horns Rev II 209MW) 2009 470m 48.4% 9-17 32  Denmark DONG [w 2][8][5]
Rødsand II 207 90 × Siemens SWP 2.3-93 54°33′36″N 11°33′0″E / 54.56000°N 11.55000°E / 54.56000; 11.55000 (Rødsand II 207MW) 2010 400m 42.1% 6-12 9  Denmark E.ON [w 3][9][10][5][11]
Nysted (Rødsand I) 166 72 × Siemens SWP 2.3-82 54°33′0″N 11°42′36″E / 54.55000°N 11.71000°E / 54.55000; 11.71000 (Nysted (Rødsand I) 166MW) 2003 248m 36.1% 6-9 11  Denmark DONG 50%, PensionDanmark 50% [w 4][12][13][5][14]
Horns Rev I 160 80 × Vestas V80-2MW 55°31′47″N 7°54′22″E / 55.52972°N 7.90611°E / 55.52972; 7.90611 (Horns Rev I 160MW) 2002 272m 39.9% 10-20 18  Denmark Vattenfall 60%, DONG 40% [w 5][5][2][12][13][15][16][17]
Middelgrunden 40 20 × Bonus/Siemens 2MW 55°41′27″N 12°40′13″E / 55.69083°N 12.67028°E / 55.69083; 12.67028 (Middelgrunden 40MW) 2000 47m 25.7% 3-6 4.7  Denmark 50% private, 50% DONG [w 6][12][13][18][19][5]
Samsø 23 10 × Bonus/Siemens 2.3-82 55°43′12″N 10°34′48″E / 55.72000°N 10.58000°E / 55.72000; 10.58000 (Samsø 23MW) 2003 30m 38.9% 10-13 4  Denmark Municipal, private [w 7][5][12][13][20]
Sprogø 21 7 × Vestas V90-3MW 55°20′24″N 10°57′36″E / 55.34000°N 10.96000°E / 55.34000; 10.96000 (Sprogø 21MW) 2009 36.5% 6-16 10  Denmark Great Belt Link [5][12][13][21]
Rønland 1 17.2 4 × Vestas V80-2MW,
4 × Bonus/Siemens 2.3-93
56°39′46″N 8°13′10″E / 56.66278°N 8.21944°E / 56.66278; 8.21944 (Rønland 1 17.2MW) 2003 44.1% 0-2 0.1  Denmark THV (Vestas), Dansk Vindenergi ApS (Bonus) [w 8][5][12][13][22][23]
Avedøre Holme 10.8 3 × Siemens SWP3.6-120 VS 55°36′0″N 12°27′30″E / 55.60000°N 12.45833°E / 55.60000; 12.45833 (Avedøre Holme 10.8MW) 2009 25m 29.2% 0-2 0.1  Denmark 50% DONG, 50% private [w 9][5][12][13][24]
Frederikshavn 7.6 Nordex N90 2.3 MW, Vestas V90-3MW,
Bonus(Siemens) 82.4 2.3 MW
57°26′40″N 10°33′40″E / 57.44444°N 10.56111°E / 57.44444; 10.56111 (Frederikshavn 7.6MW) 2003 29.3% 1-4 0.3  Denmark DONG [5][12][13][25]
Tunø Knob 5 10 × Vestas V39 500kW 55°58′10″N 10°21′20″E / 55.96944°N 10.35556°E / 55.96944; 10.35556 (Tunø Knob 5MW) 1995 £10m 29.7% 3-7 6  Denmark DONG [5][12][13][26][27]
Vindeby 4.95 11 × Bonus 450kW offshore 54°58′12″N 11°7′48″E / 54.97000°N 11.13000°E / 54.97000; 11.13000 (Vindeby 4.95MW) 1991 10m 23.8% 2-4 1.8  Denmark DONG [5][12][13][28][29]
  • "Cap." is the rated nameplate capacity of the wind farm
  • "When" is the year when the windfarm was commissioned and put into service.
  • "Cost" is the total capital cost of the project up to commissioning.
  • "Cap. Fac." is the average capacity factor, i.e. the average power generated by the windfarm, as a percentage of its nameplate capacity.
  • "km to shore" is the average distance of the windfarm to shore, or (where available) the distance from the in-farm transformer/substation to the shore
  • "Depth range (m)" is the range of minimum to maximum depths of water that the windfarm is sited in
  • "Refs" cite the source references for the information. The [w ...] footnotes link to each windfarm's own home page
Anholt
Horns Rev II
Rødsand II
Rødsand I
Horns Rev I
Middelgrunden
Samsø
Sprogø
Rønland
Avedøre
Frederikshavn
Tunø Knob
Vindeby
Locations of offshore wind farms in Danish waters

Capacity factors are averaged over each windfarm's life.[30]

Windfarm home pages

  1. Newsletter-May2013
  2. Horns Rev II turbines
  3. Rødsand II
  4. Nysted offshore wind farm
  5. Horns Rev 1 Horns Rev Offshore Wind Farm Vattenfall Horns Rev 1
  6. Middelgrunden Wind Turbine Cooperative Current turbine data
  7. Samsø Sea Wind
  8. Rønland 1
  9. DONG's Avedøre Holme Co-op

List of future sites

The list is sorted by capacity, but it can be sorted in any way by clicking once or twice on the triangle symbols ( Δ ) at the top in each column.

Wind farm Cap.
(MW)
Turbines Where When Build
Cost
Cap.
fac.
Depth
range (m)
km to
shore
Country Owner Refs.
Kriegers Flak 600 55°01′00″N 12°56′00″E / 55.01667°N 12.93333°E / 55.01667; 12.93333 (Kriegers Flak 600MW) 2021 DKK % 15-30 25  Denmark [w 1][31][32]
Horns Rev III 400 50 × Vestas V164 8MW 55°42′00″N 7°41′20″E / 55.70000°N 7.68889°E / 55.70000; 7.68889 (Horns Rev III 400MW) 2019 % 10-20 30  Denmark Vattenfall [w 2][33][34][35][36]
Vesterhav (nearshore) 350 55°0′0″N 10°0′0″E / 55.00000°N 10.00000°E / 55.00000; 10.00000 (Vesterhav (nearshore) 350MW) year 47.5 øre/kWh % shallow close to shore  Denmark Vattenfall [w 3] [37][38][39][40][41]
  • "Cap." is the rated nameplate capacity of the wind farm
  • "When" is the year when the windfarm was commissioned and put into service.
  • "Cost" is the total capital cost of the project up to commissioning.
  • "Cap. Fac." is the average capacity factor, i.e. the average power generated by the windfarm, as a percentage of its nameplate capacity.
  • "km to shore" is the average distance of the windfarm to shore, or (where available) the distance from the in-farm transformer/substation to the shore
  • "Depth range (m)" is the range of minimum to maximum depths of water that the windfarm is sited in
  • "Refs" cite the source references for the information. The [w ...] footnotes link to each windfarm's own home page
  1. Kriegers Flak Offshore Wind Farm
  2. Horns Rev III
  3. [windfarm website]

See also

References

  1. Offshore Statistics January 2009, European Wind Energy Association, data from 2008.
  2. 1 2 Steve Kopits and Adam Westwood. Offshore Wind: Time for a Market Take-off? Renewable Energy World, 8 October 2009, Table 1.
  3. "Fremskrivning af PSO-udgifter" page 4. Danish Energy Agency, 19 May 2014. Retrieved: 17 January 2015.
  4. Anholt (Denmark) offshore wind farm 4C . Retrieved: 19 May 2013.
  5. 1 2 3 4 5 6 7 8 9 10 11 12 13 Spliid, Iben B. Data on operating and decommissioned wind turbines (as at end of September 2010) (.xls spreadsheet) Danish Energy Agency, 18 October 2010. Main page Retrieved: 25 October 2010.
  6. "VIPs cut ribbon at 400MW Anholt" Recharge News, 4 September 2013. Accessed: 4 September 2013.
  7. Jan Bjerre Lauridsen & Søren Andersen. "Queen says Good Wind to giant turbines" (in Danish) Berlingske, 4 September 2013. Accessed: 4 September 2013.
  8. Horns Rev 2 (Denmark) offshore wind farm 4C . Retrieved: 30 July 2010.
  9. "Rødsand 2 wind farm online". The Copenhagen Post. 13 October 2010. Retrieved 14 October 2010.
  10. Rødsand II Wind Farm, Denmark Power Technology. Retrieved: 9 November 2010.
  11. Rødsand II (Denmark) offshore wind farm 4C . Retrieved: 8 August 2010.
  12. 1 2 3 4 5 6 7 8 9 10 Operational offshore wind farms in Europe, end 2009 EWEA. Retrieved: 23 October 2010.
  13. 1 2 3 4 5 6 7 8 9 10 Christensen, Allan S. & Madsen, Morten. Supply Chain study on the Danish offshore wind industry page 33-42 Offshore Center Denmark, 29. august 2005. Retrieved: 23 October 2010.
  14. Rødsand 1 4C . Retrieved: 31 July 2010.
  15. Horns Rev Offshore Wind Farm, Denmark Power Technology. Retrieved: 9 November 2010.
  16. Horns Rev 1 (Denmark) offshore wind farm 4C . Retrieved: 30 July 2010.
  17. Horns Revolution, Modern Power Systems, 2002-10-05, accessed 2010-04-14.
  18. Middelgrunden Offshore Wind Farm, Denmark Power Technology. Retrieved: 9 November 2010.
  19. Middelgrunden (Denmark) offshore wind farm 4C . Retrieved: 8 August 2010.
  20. Samsø Havvind (Denmark) offshore wind farm 4C . Retrieved: 8 August 2010.
  21. Sprogø (Denmark) offshore wind farm 4C . Retrieved: 8 August 2010.
  22. Windpower.net: Rønland
  23. 4cOffshore listing for Rønland 1
  24. 4cOffshore listing for Avedøre Holme
  25. 4cOffshore listing for Frederikshavn
  26. Tunø Offshore wind energy listing
  27. 4cOffshore listing for Tunø Knob
  28. Stenstrop, Georg. Vindeby Kulturarv. Retrieved: 1 September 2010.
  29. 4cOffshore listing for Vindeby
  30. "Capacity factors at Danish offshore wind farms", 18 September 2013. Retrieved: 22 October 2013.
  31. Kriegers Flak (Denmark) offshore wind farm 4C . Retrieved: 29 October 2015.
  32. Wittrup, Sanne. "Danmark tiltrækker masser af nye konsortier til kæmpe havmøllepark " Ingeniøren, 28 October 2015. Accessed: 28 October 2015.
  33. Horns Rev 3 (Denmark) offshore wind farm 4C . Retrieved: 29 October 2015.
  34. Wittrup, Sanne. "Svenske Vattenfall skal bygge Danmarks næste havmøllepark " Ingeniøren, 26 February 2015. Accessed: 26 February 2015.
  35. Vattenfall choose MHI Vestas Offshore Wind as supplier to Horns Rev 3 Vattenfall
  36. Intense competition for Kriegers Flak offshore wind farm
  37. Name (Country) offshore wind farm 4C . Retrieved: 8 August 2010.
  38. Therese Kofoed Jensen, Adviser, Danish Energy Agency (2014-03-14). "Offshore investments in Denmark" (PDF). Danish Energy Agency. Retrieved 2014-04-17.
  39. Wittrup, Sanne. "Discount-udbud af 350 MW havmøller skudt i gang " Ingeniøren, 20 February 2015. Accessed: 22 February 2015.
  40. New nearshore wind tenders
  41. "Vattenfall vinder udbuddet om de kystnære vindmøller". EnergiWatch. Retrieved 12 September 2016.
