HMS Thetis (N25)

For other ships with the same name, see HMS Thetis and HMS Thunderbolt.
HMS Thunderbolt
History
United Kingdom
Name: HMS Thetis
Builder: Cammell Laird & Co Limited, Birkenhead
Laid down: 21 December 1936
Launched: 29 June 1938
Commissioned: 26 October 1940
Fate: sunk during trial dive, 1 June 1939
Badge:
Refit: raised and refitted, 1939–40
Renamed: HMS Thunderbolt
Recommissioned: 1940
Fate: sunk 14 March 1943
Badge:
General characteristics
Class and type: T-class submarine
Displacement:
  • 1,090 long tons (1,110 t) (surfaced)
  • 1,560 long tons (1,590 t) (submerged)
Length: 275 ft (84 m)
Beam: 26 ft 6 in (8.08 m)
Draught:
  • 12 ft 9 in (3.89 m) forward
  • 14 ft 7 in (4.45 m) (aft)
Installed power:
  • 5,000 hp (3,700 kW) (diesel engines)
  • 2,900 hp (2,200 kW) (electric motors)
Propulsion:
Speed:
  • 15.25 kn (17.55 mph; 28.24 km/h) (surfaced)
  • 9 kn (10 mph; 17 km/h) (submerged)
Range: 4,500 nmi (5,200 mi; 8,300 km) at 11 kn (13 mph; 20 km/h)
Test depth: 300 ft (91 m)
Complement: 59
Armament:

HMS Thetis (N25) was a Group 1 T-class submarine of the Royal Navy which served under two names. Under her first identity, HMS Thetis, she commenced sea trials on 4 March 1939. She sank during trials on 1 June 1939 with the loss of 99 lives. She was salvaged, repaired and recommissioned as HMS Thunderbolt serving in the Atlantic and Mediterranean theatres until she was lost with all hands on 14 March 1943.[1] This makes Thetis one of the few military vessels that have been lost twice with her crew in their service history.

HMS Thetis

Thetis was built by Cammell Laird in Birkenhead, England and launched on 29 June 1938. After completion, trials were delayed because the forward hydroplanes jammed, but eventually started in Liverpool Bay under Lieutenant Commander Guy Bolus. Thetis left Birkenhead for Liverpool Bay to conduct her final diving trials, accompanied by the tug Grebe Cock. As well as her normal complement of 59 men she was carrying technical observers from Cammell Laird and other naval personnel, a total of 103 men. The first dive was attempted at about 14:00 on 1 June 1939. The submarine was too light to dive, so a survey of the water in the various tanks on board was made. One of the checks was whether the internal torpedo tubes were flooded.

Lieutenant Frederick Woods, the torpedo officer, opened the test cocks on the tubes. Unfortunately, the test cock on tube number 5 was blocked by some enamel paint so no water flowed out even though the bow cap was open. Prickers to clear the test cocks had been provided but they were not used. This combined with a confusing layout of the bow cap indicators — they were arranged in a vertical line with 5 at the bottom (2,1,4,3,6, and then 5) and the "Shut" position for tube 5 on the dial was the mirror image of tube 6 above it — led to the inner door of the tube being opened. The inrush of water caused the bow of the submarine to sink to the seabed 150 ft (46 m) below the surface. How the outer door (bow cap) to Tube 5 became open to the sea is a question that will probably never be answered, Woods maintained that until at least 10 minutes before he opened the tube all the indicators were at "Shut".[2]

Mersey Docks & Harbour Board salvage vessel Vigilant and sunken Thetis's raised stern
The stricken Thetis, surrounded by rescue boats

An indicator buoy was released and smoke candle fired. By 16:00, Grebe Cock was becoming concerned for the safety of Thetis and radioed HMS Dolphin submarine base at Gosport. A search was immediately instigated.[3] Although the stern remained on the surface, only three RN personnel (Lieutenant Frederick Woods, Captain Harry Oram and Leading Stoker Walter Arnold) and one Cammell Laird man (Fitter Frank Shaw) escaped before the rest were overcome by carbon dioxide poisoning caused by the crowded conditions, the increased atmospheric pressure and a delay of 20 hours before the evacuation started. Ninety-nine lives were lost in the incident: 51 crew members, 26 Cammell Laird employees, 8 other naval officers, 7 Admiralty overseeing officers, 4 Vickers-Armstrong employees, 2 caterers and a Mersey pilot.[4] The crew waited before abandoning the vessel until it had been discovered by the destroyer Brazen, which had been sent to search for it and which indicated her presence by dropping small explosive charges into the water.

In order to effect an escape from the stricken vessel, the escaping crew were required to enter the submarine’s only escape chamber, which can only accommodate one person at a time. As the pressure outside the submarine is greater than the pressure inside, this must be equalised before the outer door of the escape chamber is opened. The escape chamber is flooded with the occupant having to wait until the chamber is completely full of water. Only then will the pressure within the escape chamber be equal to the outside sea pressure.

In the case of HMS Thetis, 4 members of the ship’s company, three RN personnel (Lieutenant Woods, Captain Oram and Leading Stoker Arnold) and one Cammell Laird’s employee (Fitter Shaw) successfully used the escape chamber. During the 5th attempt to escape the occupant of the chamber panicked and tried to open the outer escape hatch before the chamber had completely flooded. As a result, the increased pressure outside the submarine caused an in-rush of sea water, thus drowning the escapee. Because the outer escape hatch remained partially open it rendered the escape chamber inoperative, preventing the escape of any other crew members.

The incident attracted legal action from one of the widows, who brought a claim of negligence against the shipbuilders, for not removing the material blocking the valve.[5] Unfortunately for her the Admiralty successfully invoked Crown Privilege (now termed Public Interest Immunity) and blocked the disclosure of, amongst other items, 'the contract for the hull and machinery of Thetis' as evidence in court, on the basis that to do so would be 'injurious to the public interest'.[6] The case is one of interest in English law, as the judges in this case accepted the Admiralty's claim on face value with no scrutiny, a ruling later overturned.

The Liverpool & Glasgow Salvage Association were commissioned to salvage the sunken submarine. On completion of the salvage operation the bell from Thetis was presented to the Liverpool & Glasgow Salvage Association by the Admiralty. One further fatality occurred during salvage operations, when Diver Petty Officer Henry Otho Perdue died from "the bends" on 23 August 1939. On Sunday 3 September, Thetis was intentionally grounded ashore at Traeth Bychan, Anglesey. It was the same day that war was declared. Human remains that had not already been removed by the salvage team were now brought out to a Naval funeral, with full honours.

The loss went beyond that of a submarine's crew. Among the dead were two naval constructors and several of the submarine team from Cammell-Laird; experienced designers and builders of submarines who would have been needed during the war.[7]

The Thetis disaster was in marked contrast to the successful rescue of the survivors of USS Squalus, which had sunk off the coast of New Hampshire just a week previously.

Frederick Woods remained in the Royal Navy as an officer in the surface fleet. He was killed in a car accident in 1947.[8]

HMS Thunderbolt

The crew of Thunderbolt and their 'Jolly Roger' flag, after a patrol in the Mediterranean

The submarine was successfully salvaged and repaired, being commissioned in 1940 as HMS Thunderbolt under the command of Lt. Cdr. Richard Crouch.

During the next 18 months, she saw service in the Atlantic: In December 1940 she was on patrol in the Bay of Biscay and on 15 December she encountered and sank the Italian submarine Capitano Raffaele Tarantini.

In the autumn of 1942, Thunderbolt was converted with her sister ships Trooper and P311 to carry two "Chariots" (a type of manned torpedo) and their crews for operations against Axis shipping in harbour, and was transferred with them to the Mediterranean in December 1942.

Their first mission, Operation Principal, was undertaken in December 1942, the three boats taking their charges to targets around the Mediterranean. Thunderbolt's objective was shipping in Cagliari, but the operation was not a success, and P311 was lost at La Maddalena, her intended target.

A second operation against Palermo harbour in January 1943 was more successful. On 2–3 January, the manned torpedoes entered the harbour and mined the ships there, sinking the cruiser Ulpio Traiano and the freighter SS Viminale.

A further mission to Tripoli harbour took place on 18 January. This was to prevent the Axis using blockships to neutralize Tripoli harbour, which was about to be occupied by the British Eighth Army.

Thunderbolt was sunk on 14 March 1943 off Sicily by the Italian corvette Cicogna,[9] which had detected her and attacked with depth charges. All hands were lost and Thunderbolt settled to the bottom in 1,350 m of water.

The Thetis clip

The torpedo tubes on British and Australian submarines were afterwards equipped with a "Thetis clip", one of the modifications introduced as a result of the accident. This is a latch which allows a torpedo tube door to be opened no more than a small amount in case it is open to the sea at the bow end. Once it is clear that no flooding will occur the latch can be released and the door fully opened.

Appearance in the media

In 1997, BBC Radio 4 broadcast a radio play about the Thetis disaster. The play was called Close Enough To Touch and was written by Liverpool writer Fred Lawless. The play was also broadcast on BBC Radio Merseyside and the BBC World Service. In 1999, a play entitled HMS Thetis by Mark Gee in association with David Roberts, was performed at the Liverpool Bluecoat Chambers and at Birkenheads Pacific Road Theatre. The play starred John McArdle and also the newly employed First Year Apprentices from Cammell Laird Shipyard, (Paul Gillies, Dave Gill, Alan Lane, Chris Motley, Mike Jebb, Steve Taylor, Ollie Dodson, Stuie Dicken, Mark Poland, Ben McDonald, Tony Cummins, Barry Hayes, Chris Hall, Martin King, Graham Crilly, Billy Coburn, Matty Brassey,)

The cause of the loss of Thetis was also used in the 1968 film Ice Station Zebra, where the character played by Patrick McGoohan describes a method of sabotaging a submarine by blocking the tube test cocks, allowing the inner door to be opened with the outer door also open.

The loss of the Thetis was the inspiration for part of the "Railway station" episode (episode 2) of British dark science fiction television series Sapphire & Steel.

In 2000 the documentary "Death in the Bay", produced by BBC Northwest, was broadcast in the UK. It covered the loss of the vessel and the subsequent enquiry, together with interviews with relatives of two of the men lost in the tragedy and the son of a survivor, Leading Stoker Arnold.
